Raptor 700
 |
| Raptor 700 Motor Package……$1350.00 Kit includes: CT head porting, 5 angle radius Race valve job, Web cam, honing your cylinder to extract maximum performance and fitment of a hi performance piston 11/1 (pump gas) or 12.5/1 (100 octane) piston kit, valve spring kit with titanium retainers, new OEM valve cotters and top-end gasket set. |
| Raptor 700 HIGH Output Motor Package……$1595.00 Kit includes: CT head porting, +1mm or +2mm oversized intake and exhaust valves, 5 angle radius race valve job, Web cam, honing your cylinder to extract maximum performance and fitment of a hi performance piston 11/1 (pump gas) or 12.5/1 (100 octane) piston kit, valve spring kit with titanium retainers, new OEM valve cotters and top-end gasket set. |
| Both packages your cam is required as a core. Just ship us your complete top end, Cylinder and Head along with a good stock cam to receive either package. The 11/1 piston is best for 91 octane pump gas and the 12.5/1 requires 100 octane gas. This can be attained by mixing 108-112 race gas 50/50 with 91 octane pump gas. This kit price is for you shipping us your top-end only. We have been tuning and setting them up as we would one of our Baja race quads for good power and durability. We have been posting well over 60 horsepower on the dyno running this set up. A 60+ horsepower motor with high torque numbers (50+ ft lbs) makes the Raptor seriously fast and a blast to ride with lots of bottom. These kits are offered as a motor only package.We highly recommend our CT Racing pipe kit to be used with both kits and the fuel management program is required. We have had great success with the Dynatek F.I. Controller, MSD Blaster and the Dynojet Power Commander III and V. The Dobeck Gen 3 will work, but the Dobeck Gen 2 will not. |
| PLEASE NOTE: Your head is returned assembled and ready to bolt on and run. This kit price is for you shipping us your top-end only. If you would like to ship us your complete motor, add $250.00 for R&R of top-end. |
| CLICK Here for Shipping Instructions for Your Motor |
 |
 |
| Description | Price | Photo |
 |
||
| 06′-’14 Raptor 700 Pipe Kit | $538.95 |
 |
| CT Spark Arrestor 11 Disc End Cap Kit with Bolts | 129.95 |  |
| ATV Exhaust Turn Down End Cap –Turn down tip includes 6 stainless steel bolts. | $59.95 |
 |
 |
||
| Head Porting – CT Racing has done significant amounts of flow bench and dyno testing to offer you the best port layout for your application. We highly recommend getting a valve job at the same time the head is being ported. Our CNC valve job ties in with the port work to offer extremely effective flow numbers. | $350.00 |  |
| 3 Angle Valve Job – Quality valve job. | $144.00 |  |
| 5 Angle Radius Race Valve Job – The 5 angle radius Race valve job significantly raises the flow characteristics at low valve lift and definitely shows a horsepower increase throughout the useable power curve. | $192.00 |  |
| 5 Angle Radius Race Valve Job for +1mm Intake & Exhaust Valves – The 5 angle radius Race valve job significantly raises the flow characteristics at low valve lift and definitely shows a horsepower increase throughout the useable power curve. The 5 angle valve job really shines on big valves as the seat diameter is opened up all the way into the aluminum casting, blending to the port work. Adding +1mm valves to a modified engine package helps the mid to top-end horsepower. Most aftermarket hi compression pistons are clearanced for +1mm valves. | $240.00 |  |
| Split 4 Stroke Cases, Inspect Crank & Trans, & Reassemble | $575.00 | |
| Disassemble & Reassemble 4 Stroke Top-end (From bottom-end only) | $300.00 | |
| Disassemble Head, Clean Ports, Prep, & Reassemble | $95.00 | |
| Rebuild 4 Stroke Crankshaft (Labor only) | $110.00 | |
 |
||
| Dura Blue Foam Air Filter | $38.97 |
 |
| Pro Design Pro Flow Foam Air Filter Kit | $154.45 |
 |
| Pro Design Pro Flow Replacement Foam Air Filter | $42.75 |
 |
| Pro Design Pro Flow K&N Air Filter Kit | $182.95 |
 |
| Pro Design Pro Flow Replacement K&N Air Filter | $66.45 |
 |
| Fuel Customs Intake System – System includes a high horsepower intake, Fuel Customs K&N type air filter, and Outerwear. The system comes with or without an air box. Can not be used with stock air box. |
|
 |
| Fuel Customs Replacement Filter and Cover – Need an extra filter or a replacement? This filter is for fuel custom intakes ONLY! | $65.00 |
 |
 |
||
| ’06-’14 Raptor 700 CT Racing 741cc Big Bore Kit – Includes New 106mm big bore cylinder, JE hi performance 12.5/1 piston kit, and Cometic EST complete top-end gasket set. | $699.95 |
 |
 |
||
| ’15-’17 Raptor 700 CP Piston Kit 102mm – Available in 11:1, and 12:1 Comp Ratios. | $295.00 |
 |
| ’06-’14 Raptor 700 CP Piston Kit 102mm – Available in 11:1, and 12:1 Comp Ratios. | $295.00 |
|
| ’06-’14 Raptor 700 CP Piston Kit 105mm – Available in 10.75:1, 12:1, and 13:1 Comp Ratios. | $295.00 |
|
| ’06-’14 Raptor 700 CP Piston Kit 105.5mm – Available in 10.75:1, and 12.5:1 Comp Ratios. | $295.00 |
|
| ’15-’17 Raptor 700 JE Hi Performance Piston Kit 102mm – Available in 10:1, 11:1, and 12.5:1 Comp Ratios. | |
 |
| ’15-’17 Raptor 700 JE Hi Performance Piston Kit 103mm – Available in 10:1, 11:1, and 12.5:1 Comp Ratios. | |
|
| ’06-’14 Raptor 700 JE Hi Performance Piston Kit 102mm – Available in 10:1, 11:1, and 12.5:1 Comp Ratios. | |
|
| ’06-’14 Raptor 700 JE Hi Performance Piston Kit 103mm – Available in 12.5:1 Comp Ratio. | |
|
| ’06-’14 Raptor 700 JE Hi Performance Piston Kit 104mm – Available in 11.4:1 Comp Ratio. | |
|
| ’06-’14 Raptor 700 JE Hi Performance Piston Kit 105.5mm – Available in 10:1, 11:1, and 12.5:1 Comp Ratios. | |
|
| ’06-’14 Raptor 700 JE Hi Performance Piston Kit 106mm – Available in 12.5:1 Comp Ratio. | |
|
| ’06-’14 Raptor 700 Wossner Hi Performance Piston Kit 102mm – Available in 11:1 Comp Ratio. | |
 |
| ’06-’14 Raptor 700 Wossner Hi Performance Piston Kit 103mm – Available in 11:1 Comp Ratio. | |
|
| ’06-’14 Raptor 700 Wossner Hi Performance Piston Kit 104mm – Available in 11:1 Comp Ratio. | |
|
| ’06-’14 Raptor 700 Vertex Hi Performance Piston Kit 102mm – Available in 9.2:1 and 11:1 Comp Ratios. | $149.99 |
 |
| ’06-’14 Raptor 700 Vertex Hi Performance Piston Kit 105mm Big Bore 727cc – Available in 9.2:1 Comp Ratio. Aftermarket cylinder sleeve required. | $169.95 |
|
| Raptor 700 Cometic Complete Top-end Gasket Set – Available in 103mm, 104mm, and 105.5mm. Available in EST = Extreme Seal Technology (includes valve stem seals). | $53.20 |
 |
| Raptor 700 Winderosa Complete Gasket Set – This complete engine gasket set also includes all of the engine oil seals – crank, countershaft, and ETC. Winderosa Gaskets are extemely high quality US made gasket sets. | |
 |
| ’06-’14 Raptor 700 Hot Rods Connecting Rod – Available in stock stroke. | |
 |
| ’06-’14 Raptor 700 Hot Rods Crank – Available in Stock Stroke or +5mm Stroker. Main bearings not included. | |
 |
| ’06-’14 Raptor 700 Hot Rods Heavy Duty Complete Bottom End Kit – Available in Stock Stroke or +5mm Stroker. This kit includes main bearings, seals, gaskets, and crank. | |
 |
| ’06-’08 Raptor 700 Web Cam Camshaft – Available in MX or Hi-rev Drag builds. Requires valve spring kit part #EC-KW-80-80410 | |
 |
| ’09-’14 Raptor 700 Web Cam Camshaft – Available in MX or Hi-rev Drag builds. Requires valve spring kit part #EC-KW-80-80410 | |
|
| ’15-’17 Raptor 700 Web Cam Camshaft – Available in MX or Hi-rev Drag builds. Requires valve spring kit part #EC-KW-80-80410 | |
|
| ’06-’08 Raptor 700 Hot Cam Camshaft – Available in Stage 1, Stage 2 , and Stage 3 | |
 |
| ’09-’14 Raptor 700 Hot Cam Camshaft – Available in Stage 1, Stage 2 , and Stage 3 | |
|
| Raptor 700 Kibble White Stainless Steel Valves – Available in Standard, +1mm, and +2mm Oversized in both Intake or Exhaust Valves. | |
 |
| Raptor 700 Kibble White Racing Valve Spring Kit with Retainers – This Kit (EC-KW-80-80410) is Recomended to use with above Kibble White Valves. | |
 |
 |
||
| Hinson Billetproof Clutch Basket | |
 |
| Hinson Clutch Kit – Includes Fibers, Steels, & Springs. | |
 |
 |
||
| Fasst 1-1/8″ Flexx Bars – These are the best off road bars money can buy. Bars come with three different elastomers to get the proper cushioning for your type of riding along with a cross bar pad in your color choice of blue, grey, or red. Please Note: 1-1/8″ bar mount kit is required. | $359.95 |
 |
| Streamline Reflex Pro Pack with Clutch and Brake Lever – Available in Black, Blue, Red, and Orange. |
|
 |
| Streamline Steering Stabilizer 7-Way Adjustable Non-Rebuildable – Available in Silver, Red, Blue, or Black. |
|
 |
| Streamline Steering Stabilizer 7-Way Adjustable Rebuildable – Available in Silver, Red, Blue, or Black. |
|
 |
| Streamline Steering Stabilizer 11-Way Adjustable Rebuildable – Available in Silver, Red, Blue, or Black. |
|
 |
| Streamline Steering Stabilizer Carbon 11-Way Adjustable Rebuildable – Available in Silver, Red, Blue, or Black. |
|
 |
| Pro Design Tether Kill Switch – Available in Black, Blue, or Red | $36.95 |
 |
| CV4 Billet Tether Kill Switch Mount – Handlebar mount for Pro Design and Pro Armor tether kill switches.This mount allows you to mount your switch to the bar without using up all of the spacing. Allows you to mount the switch much closer to the bend. Available in Black and Red. | $49.95 |
 |
 |
||
| Streamline Steel-braided Front Brake Line Kit – (Please specify color & length) Available in black, blue, clear, green, red, or smoke. Some colors and lengths may need to be special ordered. | |
 |
| Streamline Steel-braided Rear Brake Line – (Please specify color & length) Available in black, blue, clear, green, red, or smoke. Some colors and lengths may need to be special ordered. | |
 |
| Billet Brake Line Clamp – 1 pair (Please specify color) Can be used with any 3/4″ or 1″ diameter A-arm. Available in black, blue, red, or silver. | |
 |
 |
||
| Lone Star Racing Anti-vibration Steering Stem – Available in +1″ exteneded length and 7/8″ or 1 1/8″ Handlebar clamps included. |
|
 |
 |
||
| Lone Star Racing Axcaliber Axle – Axcalibar Pro Racing Axles are one of the most highly recommended axles on the market for both racers and recreational riders. | $525.00 |
 |
| Lone Star Racing Dual Row Bearing Carrier – The billet aluminum bearing housings are machined from 6061 aluminum for superior housing strength. | |
 |
| Dura Blue Heavy Duty Axle – This axle is a recreational level axle thatis twice the strength of the stock axle. It’s a cost effective choice when reliability is a prime concern. | |
 |
| Dura Blue Eliminator 2+2 Extended Axle – The Eliminator axle used for all forms of racing and high performance applications. Many of the models come with the patented Posi•Lock system which removes threaded sections from the flexing area of the shaft (a source of crack generation). | |
 |
| Dura Blue Eliminator X-33 Pin Drive Axle with CAST Hubs – The X-33 axle uses the same superior material and heat treating as the Eliminator. The unique difference is in the design of the wheel hub mounting area. Standard design ATV axles neck down to about 1″ in diameter. A splined wheel hub slides onto the axle shaft and is retained with a hex nut. As all ATVer’s know, hubs loosen frequently. The X-33 changes all that. The wheel hub is clamped solid and driven by a pin on a 1-3/8″ diameter shaft. This axle is rifled to reduce weight near the rotational axis of the ATV. The X-33 allows for 16 different wheel offset alternatives. | |
 |
| Dura Blue Eliminator X-33 Pin Drive Axle with BILLET Hubs – This X-33 axle uses the same design, superior material and heat treating as the X-33 w/ cast hubs. The unique difference is in the wheel hub and that they are billet aluminum for superior strength. |  |
|
